Tandem Phoenix

The CPS Tandem Phoenix (TP) Series is an advanced medium-high aspect ratio, moderately tapered, nine-cell tactical main canopy offering an increase in maximum suspended weight capability and is the flagship canopy for Military Tandem Tethered Bundle (MTTB) operations. The TP Series canopies provide optimal offset performance while yielding lighter toggle pressure and increased landing performance during the flare maneuver throughout the lifespan of the canopy.

The TP-Series canopy is available in multiple configurations: M1, M2 and M3.

TP-M1 – compatible with self-set and static line drogue, and hand deploy pilot chute operations
TP-M2 – compatible with self-set and static line drogue, hand deploy pilot chute, and double bag static line operations
TP-M3 – compatible with self-set and static line drogue operations

The TP-360 is a smaller tactical tandem canopy for working loads up to 550 lbs, and is also well suited for solo operators with heavy rucks as well as K9 operations. Constructed from zero-porosity ripstop nylon. Available in the M1 and M2 configuration.

The TP-400 is constructed from zero-porosity ripstop nylon and has a carriage capacity of up to 650 lbs. Available in the M1 and M2 configuration.

The TP-460 has a carriage capacity of up to 850 lbs. Construction using a hybrid design, the TP-460 has a zero-porosity ripstop nylon top surface with 1.1 oz 0.5-3 cfm nylon ripstop in the remainder of the canopy. Available in the M3 configuration.

Attributes

• 9-cell tactical main tandem canopy
• TP-360/TP-400 zero-porosity ripstop nylon
• TP-460 hybrid canopy construction
• Optimal offset performance
• Increased landing performance
• Maximum weight up to 850 lbs
• Available in the M1, M2 or M3 configuration
